High Air Pressure Reverse Circulation DTH Hammer with 4.5inch Hammer Size and 113mm-130mm Hole Range

Name: High Air Pressure Reverse Circulation DTH Hammer with 45inch Hammer Size and 113mm130mm Hole Range
Brand: SOLLROC
Price: 1 USD

Quality High Air Pressure Reverse Circulation DTH Hammer with 4.5inch Hammer Size and 113mm-130mm Hole Range for sale

Place of Origin : Hunan, China

Brand Name : SOLLROC

MOQ : 1

Price : $1,500

Weight : 55.0kg

Hammer Size : 4.5inch

External diameter : 109.5mm

Length : 1191mm

Hole range : 113mm-130mm

Material : Carburized steel

Bit shank : SRC542

Connection thread : 3.5''/4''Remet 4''Metzke

Working Pressure : 1.5-3.5Mpa

Impact rate : 35HZ

Rotation speed : 25-40r/min

Air consumption : 12m³/min, 18m³/min, 26m³/min

Type : hammer

Machine Type : Drilling Equipment

Thread : Metzke/ Remet

Contact Now

Product Description

Reverse circulation drilling is similar to air core drilling as the samples that are drilled up from the earth are not simply placed onto the surface surrounding the machine but the samples are instead shot up into the hollow pipe of the machine. This is one of the biggest benefits of the reverse circulation drilling procedure because it prevents the samples from being contaminated from other materials that it might come into contact with once it has been removed from the earth.

Advantages

1. Although the process can be costly the overall drilling costs can actually be reduced by up to 40% when using reverse circulation drilling.

2. Results from reverse circulation drilling can be revealed much faster as the completion of the drilling process is done quickly.

3. The method is safe to use and requires fewer man hours.

4. Reverse circulation drilling requires less water than other mining methods.

5. Reverse circulation drilling is simple and easy.

6. Samples can be easily arranged into boxes stating where the sample was collected and at what depth the sample was collected which will help those studying the samples to pinpoint exactly where the mineral deposit is located. This will help a mining company or a group of researchers to quickly and easily locate the exact area and depth from which the sample was discovered.

Technical Parameters

Length (less bit)	Weight (less bit)	External diamater	Bit shank	Hole range	Connection thread
1191mm	57.0kg	109.5mm	SRC542	113-130	3.5''/4''Remet 4''Metzke
Working Pressure	Impact rate at 2.4Mpa	Recommended rotation speed		Air consumption
1.5-3.5Mpa	35HZ	25-40r/min		1.7Mpa	2.4Mpa	3.0Mpa
1.5-3.5Mpa	35HZ	25-40r/min		12m³/min	18 m³/min	26 m³/min

Packing & Delivery

High Air Pressure Reverse Circulation DTH Hammer with 4.5inch Hammer Size and 113mm-130mm Hole Range

Ply-wooden cases

Ply-wooden cases + Pallet

Delivery

By air, By sea or by Express
